ATI HD1601
| 8Ω stereo power | 2x1700W |
| 4Ω stereo power | 2x2250W |
| 8Ω Bridge Mono Power | 4200W |
| 4Ω Bridge Mono Power | 5200W |
| Max Peak Output Power | 138v |
| Frequency Response | 20Hz-20kHz -3dB@150KHz |
| THD+N（8Ω 1KHz in 1/4 Output)% | ＜0.1% |
| Damping Factor | >1000 |
| Standard Input Sensitivity (rate power of 8Ω) | 0.775v |
| Input Impedance (balanced and unbalanced) | >20kΩ>10k |
| Class | H |
| Input connectors(per ch.) | 3-pin XLR, electronically balanced |
| Link connectors(per ch.） | XLR, 3 pin male |
| Cooling | Two rear panel variable speed DC fans, filters detachable without tools |
| LED Indicators (per channel) | Clip/Limit, Signal, Temp/DC, Active |
| Net Weight | 40kgs |
| Gross Weight | 42kgs |
